Spherical Ordinary Horizontal Lathe

The spherical lathe is mainly used for turning the outer spherical surface of the ball core body of the ball valve. Processing spherical diameter 550mm--1800mm. It can realize finishing turning, semi-finishing turning, grinding and other processing work. The bed adopts rectangular guide rails, which has good stability and rigidity. The spindle adopts a three-support structure, which has high rigidity, high precision, and can perform powerful cutting. Users can freely choose or make special orders according to the size of the workpiece to be processed and the purpose of the machine tool

Project	unit	C6555	C6595	C65160	C65180
Maximum diameter of processing spherical surface	mm	550	900	1600	1800
Minimum diameter of processing spherical surface	mm	50	260	1000	1200
Spindle bore diameter	mm	100	130	100	100
Spindle taper diameter	mm	120	140	140	140
Spindle speed types		18	21(reverse12)		21
Spindle speed range	r/min	6-800	3.15-315
Spindle reverse range	r/min	11-838	3.5-291
Tool holder rotation angle	º	±90º		±55º
Main motor power	kw	11	22	30	30
Net weight	t	4.4	12	25.4	27.4
Machine lenght	mm	3725	4700	6120	6220
Machine width	mm	1280	2500	2620	2720
Machine height	mm	1690	2000	2520	2620
