Project |
unit |
CKH61125E |
CKH61160 |
CKH61180 |
CKH61200 |
|
Capacities |
|||||
|
Maximum rotation diameter of bed |
mm |
1250 |
1600 |
1800 |
2000 |
|
Maximum cutting diameter |
mm |
900 |
1250 |
1450 |
1600 |
|
Maximum work piece length |
mm |
3000/5000/6000/8000/10000/12000 |
|||
|
Maximum cutting length |
mm |
2800/4800/5800/7800/9800/11800 |
|||
|
Bed rail width |
mm |
1100 |
|||
|
Spindle |
|||||
|
Spindle end code |
mm |
A2-15 |
|||
|
Spindle through hole diameter |
mm |
100 |
|||
|
Spindle front tapered hole |
Metric140 |
||||
|
Spindle speed range |
r/min |
CKH3.15-320; CKHJ:Forward3.15-315/reverse3.5-291 |
|||
|
Spindle speed types |
CKH:Infinitely variable speed;CKHJ:manual level 21 |
||||
|
Spindle center height |
mm |
500 |
625 |
700 |
820 |
|
Weight capacity |
t |
16 |
|||
|
chuck |
mm |
Four claws 1250 |
|||
|
Feed |
|||||
|
Maximum main cutting force |
N |
39200 |
|||
|
X,Z direction rapid movement speed |
mm/min |
4000/6000 |
|||
|
Maximum travel in X direction |
mm |
850 |
|||
|
Turret |
|||||
|
Number of tool holder stations |
V4 |
||||
|
Tool holder size |
mm |
380*380 |
|||
|
Maximum X-direction feed force |
N |
10875 |
|||
|
Toolbar section |
mm |
50*50 |
|||
|
Tailstock |
|||||
|
Tailstock sleeve diameter |
mm |
260 |
|||
|
Tailstock sleeve travel |
mm |
300 |
|||
|
Tailstock sleeve tapered hole |
Merric80 |
||||
|
Others |
|||||
|
Workpiece accuracy |
IT7 |
||||
|
Workpiece surface roughness |
µm |
Ra1.6-3.2 |
|||
|
Main motor power |
kw |
30 |
|||
|
Machine quality |
t |
CKH61125:1500/19400/21560/26000/30400/34800 |
|||
|
Machine length |
mm |
CKH61125:6400/8400/9400/11400/13400/15400 |
|||
|
System Configuration |
Fanuc (customizabie) |
||||
